Kit Building

OzarkCon QRP Conference 2023
Kit Building Workshop
Friday Evening - March 31, 2023
This year's Build Session kit is the newest member of the 4SQRP family of kits.
The '4S-Dummy Load' is a 10W SMT dummy load and power meter device that uses LEDs to indicate power levels
Works with all Amateur Radio bands
No external power needed
Maximum output power: 10 Watts.
Power Indicator LEDs: 0.5w, 1w, 2w, 5w
Assembly time:
With only 15 large SMT and 7 through hole components, this is a simple kit, with a completion time of 30 to 90 minutes.
The price of the Build Session kit is $10, and is selected and paid for during the registration process. You must attend the session for this special price.
This is a great fun & fellowship activity for all, experienced builders or not, so plan to attend and enjoy AND you will get to carry home this years nifty kit selection that you built. Pre-Registration is necessary as there is a limited number of the kits available for the building session.
Attendees will need to bring their own hand tools for the session.
✔Soldering iron with a stand. A small tip on the iron is suggested. This could be a simple 25 watt iron with a bent coat hanger stand.
✔Damp sponge to clean the soldering iron tip
✔Rosin core solder - Kester "44" or similar. Note that we will have some spare solder available
✔Small wire cutters
✔Needle nose pliers
✔Magnifier and/or light
✔Hilighter to mark off parts as they are installed
✔Cookie sheet with upturned lip to catch stray parts, to reduce static discharge damage to components and to protect the table surface
Four State QRP Group volunteers coordinate and supervise the OzarkCon Friday Night Build Session.
